Steel c profile roll forming machine can produce many sizes of C shape purlin. Main equipment include: Decoiler, main forming system, punching equipment, post cutting equipment, hydraulic station, and electric controlling system. Our steel c profile roll forming machines are widely used nowadays in all around the world. The c purlin our machine produced are widely used in the house building, the solar panel support project. Our machine are customized, we will produce our machine as your c purlin profile drawings.
Steel c profile roll forming machine Decoiler System:
Loading capacity: 3 T
Uncoiling width: 500 mm
Inner diameter: 450-550 mm
Steel c profile roll forming machine Roll Forming System:
Main power: 11 kw
Drive mode: Chain
Number of rollers: 12 rollers
Diameter of shafts: φ 60 mm
Weight of main part: About 8 tons
Frame type: Memorial arch frame
Material of shafts: 45# steel with tempering
Material of rollers: GCr15 quench with 58-60°
Forming speed: 8-12 m/minute (with punching)
Voltage : 380 v 50 hz 3 phase (as customer`s request)
Size of the main part: About 8800 х1800х 1400mm(L*W*H)
Steel c profile roll forming machine Automatic Cutting System:
Power supply: Hydraulic power
Material of blades: Cr12mov quenched
Components: It contains one set of blade, one hydraulic tank and one cutter machine.
Steel c profile roll forming machine Electric Control System:
Length Tolerance: 3m±1.5mm
Automatic length measurement
Language: English and Chinese
Automatic quantity measurement
Length inaccuracy can be amended easily.
Voltage: 380 v 50 hz 3 phase (as customer`s request)
Operating panel: touching screen and button together.
Steel c profile roll forming machine Our Service:
1. One year warranty, whole life technical support.
2. Installation & adjustment: We can take a video for the customer and the customer can also come to our factory, we can train customer how to install and adjust the machine.
3. Oversea service: the buyer should charge of visa, return ticket, food and accommodation overseas and USD50/person/day salary.
Looking for ideal Profile Roll Forming Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the C Profile Roll Forming Machine are quality guaranteed. We are China Origin Factory of Steel C Profile Roll Forming Machine. If you have any question, please feel free to contact us.
Product Categories : C/Z/U Purline Roll Forming Machine > U Bracket Solar Power Stent Manufacturing Series
