Trinity Highway Guardrail Making Machine

    Unit Price: USD 12500 - 49800 / Set/Sets
    Payment Type: T/T,L/C,D/A,D/P
    Incoterm: FOB
    Min. Order: 1 Set/Sets
    Delivery Time: 25 Days
Basic Info

Model No.: ZT-005-81

Additional Info

Packaging: As the Customer's Requirement

Productivity: 10-15m/min

Brand: ZHONGTUO

Transportation: Ocean,Land,as customer requirem

Place of Origin: China

Supply Ability: 30 sets/month

Certificate: ET, ISO9001

Product Description

Trinity Highway Guardrail Making Machine

Trinity Highway Guardrail Making Machine also known as highway guardrail forming machine, can be widely used for making a variety of guardrails, such as highway guardrail, fence and pasture fence.The highway guardrail forming machine is mainly consisted of uncoiler, punching system,feed leading table, main forming machine, cutting device, hydraulic station and computer control system.

Highway Guardrail Forming Machine


Working process:

Trinity Highway Guardrail Making Machine

Detailed information of Trinity Highway Guardrail Making Machine:

Hydraulic decoiler

Usage: It is used to support the steel coil and uncoil it in a turntable way.Passive uncoil pulled by roll forming System.

1.ID:500-550mm

2. Coil width:500mm

3. Loading ability:5000kg

4. Hydraulic power:3kw

5.Motor:3kw

Highway Guardrail Forming Machine

Feeding and leveling part

1. Roller material after quenching

2. 9 rows station for leveling: 4 5

3. The diameter of raw material 95mm ,45 steel after quenching

4. Feed a side wheel GCR15 raw materials, after quenching

Guardrail Forming Machine

Punching and shearing part

1.Hydraulic punching, raw material after quenching Cr12,Which can be welded, which need to bolt

2.Shearing blade material:Cr12 after quenching.

3. Shear error: +/- 2mm

Two Wave Highway Guardrail Forming Machine

Feeding coil part

1. Feeding coil table:

2. Main power:3kw

3. Length:6M

Trinity Highway Guardrail Making Machine

Roll Forming Machine

Advantage: to make sure long time using, working steady and high speed.

1. Main-length: about 20.5*1.2*1.5m

2. Machine weight: 15.5 Ton

3. Voltage: customer choice

4. Fix wheel types: medium plate

5. Frame: 400# steel

6. Transmission: Chain

7. Shaft material: 45 steel after adjusting treatment, the diameter of 100mm, precision machining

8.Roller material: GCR15, after quenching, and after chrome wheels.High strength bolt

9. Rolling station:20 stations

10.Main power:45kw

Highway Guardrail Forming Machine

Hydraulic system

1.Power: 18.5kw

2.Hydraulic oil type: 46#

3.Component: the system includes a set of one or two sets of hydraulic oil tank, hydraulic pump, hydraulic pipe line four, two sets of solenoid valve.

Highway Guardrail Forming Machine

Electrical system

Advantage:

1.Panasonic 1.5.7 inch touch screen is Japan's Panasonic brand, to ensure high speed and stability, accuracy and service life.

2.Panasonic PLC, Panasonic inverter

3. automatic fixed length

4. automatic counting

Automatic stop shear length control. Equipped with 5 movable switch, fuse, radiator, transformer and convenient operation and safety of leakage protector.

Trinity Highway Guardrail Making Machine

Looking for ideal Highway Guardrail Forming Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Two Wave Highway Guardrail Machine are quality guaranteed. We are China Origin Factory of Guardrail Forming Machine. If you have any question, please feel free to contact us.
