Road Barrier & Guardrail Making Machine

    Unit Price: USD 28000 - 64000 / Set/Sets
    Min. Order: 1 Set/Sets
    Delivery Time: 45 Days
Basic Info

Model No.: ZT-005-50

Additional Info

Packaging: naked packing

Productivity: 8m/min

Brand: zhongtuo

Place of Origin: China

Supply Ability: 30 sets per month

Certificate: CE ISO9001

Product Description

Road Barrier & Guardrail Making Machine

Function:

Road Barrier & Guardrail Making Machine is the equipment to press, through rolling and cold bending, the colored steel sheet with thickness of 0.5-4.5mm into two waves pattern sheet. The machine is suitable for the use of road barrierand has the following characteristic: light weight, high strength, rich colors and being earthquake-proof and fireproof, etc. Now the machine is widely used. It has advantage of pretty appearance, durable using ,longlife ,low energy consumption and so on.

Final products and profile:

Road Barrier & Guardrail Making Machine

Road Barrier & Guardrail Making Machine Process Flow:

Uncoiling→Feeding material into machine→Punching → Roll forming→Measuring length→ Auto cutting→Products receiving

Road Barrier & Guardrail Making Machine

Components of Road Barrier & Guardrail Making Machine

Suitable Material Type:GI/PPGI/AL

coil width:488mm

Length Tolerance:±2mm/6m

Working Speed:25 m/min Standard machine

Total Power: 30KW

Total Weight: About 15T Up to final design


Un-coiler System

Usage: It is used to support the steel coil and uncoil it in a turntable way.

Passive uncoil pulled by roll forming system

Decoiler

Coil feeding part of Highway Guardrail Roll Forming Machine

Usage: Put the raw material leveling by 9 rollers four up and five down. GCR15 45#steel raw materials with quenched treated ,diameters is 95mm.(steel plate) through the beach to manufacture and process,it can guarantee that the products are neat, parallel and everything is uniformity.Please refer to the equipment regulation to know the function of locate angle iron.

feeding


Punching device

Hydralic punching .Raw materail cr12 treated with quenched .

punching

Feeding rack

table for Road Barrier & Guardrail Making Machine

Forming device

Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive, chain transmission,roller was chromed which can keep the molding plate surface smooth and not easy to be marked when it is working

roll forming for Road Barrier & Guardrail Making Machine


Length of the main part:18500*1200*1500mm

Weight of main part:About 15 t

Voltage:380V/50HZ3Phase (as customer`s request)

Roller fixer:Guide column

Frame:Middle plate welded ,Memorial arch frame type

Frame thickness:25mm

Drive mode:case of different speed

Material of rollers:45# steel with tempering

Material of shafts:45# steel with tempering

Diameter of shafts:φ95mm

Number of rollers:16rollers

Main power:30kw (Cycloidal planetary gear speed reduce

Drive mode : case of different speed

Cutting device

Advanced hydraulic drive, automatic punching and cutting after forming, no distorting or wasting, high level safety

factor.

cutting for Road Barrier & Guardrail Making Machine

Spare parts ( for free)

1. Easy damaged parts: conk 2 pcs, fuse-link 4 pcs;

2. Rubber mat 1 pcs;

3. Bolt spanner 1 pc


Looking for ideal Road Barrier Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Guardrail Sheet Roll Forming Machine are quality guaranteed. We are China Origin Factory of Highway Guard Rail Machine. If you have any question, please feel free to contact us.
