Zhongtuo Roll Forming Machinery Co., ltd

metal steel drywall stud & track cold rolled machine
metal steel drywall stud & track cold rolled machine
metal steel drywall stud & track cold rolled machine
metal steel drywall stud & track cold rolled machine
metal steel drywall stud & track cold rolled machine

metal steel drywall stud & track cold rolled machine

Unit Price: USD 13500 / Set/Sets
Payment Type: L/C,T/T,D/P,Paypal,Money Gram,Western Union
Incoterm: FOB,CFR,CIF,FCA,CPT
Min. Order: 1 Set/Sets
Delivery Time: 30 Days

Contact Now Add to Basket

Basic Info

    Model No.: ZT-006

    Name: Metal Steel Drywall Stud & Track Cold Rolled Machi

    Drive Mode: By Gear

    Material Of Rollers: GCr12MoV

    Material Of Shafts: 45# Steel With Tempering

    Diameter Of Shafts: 40mm

    Number Of Rollers: 11 Rollers

    Material: GI/PPGI

    Material Thickness: 0.3-0.6 Mm

    Forming Speed: 25 Meter/minute

    Language: English And Chinese

Additional Info

    Packaging: as customer's need

    Productivity: 25-50m/min

    Brand: zhongtuo

    Transportation: Ocean,Land,Air

    Place of Origin: China(mainland)

    Supply Ability: 30 sets/month

    Certificate: CE,ISO,SGS,IAF,CNAS.

    HS Code: 84552210

    Port: XINGGANG PORT,TIANJIN CHINA

Product Description

metal steel drywall stud & track cold rolled machine

Our metal steel drywall stud & track cold rolled machine is widely used in all around the world. This metal steel drywall stud & track cold rolled machine have two forming lines, but they have seperated control systems, this kind of drywall metal process roller mahcine will save the space for the factory. And the products this machine produced is mainly used for the drywall and the ceiling structure. The speed of our Light gauge steel frame machine can reach 50 meters per minutes, of course this machine price is a little higher than the 25 meters speed machine. We will produce this machine as your personal requirements.

metal steel drywall stud & track cold rolled machine Customer requirements:

metal steel drywall stud & track cold rolled machine

metal steel drywall stud & track cold rolled machine Working Process:

metal steel drywall stud & track cold rolled machine

metal steel drywall stud & track cold rolled machine Decoiler System
Usage: It is used to support the steel coil and uncoil it in a turntable way. Passive uncoil pulled by roll forming system.
Loading capacity: 1.5T
Uncoiling width: 300mm
Inner diameter: 450-550mm

metal steel drywall stud & track cold rolled machine

metal steel drywall stud & track cold rolled machine Entry Beach
Usage: Put the raw material (steel plate) through the beach to manufacture and process, it can guarantee that the products are neat, parallel and everything is uniformity. Please refer to the equipment regulation to know the function of locate angle iron.

metal steel drywall stud & track cold rolled machine

metal steel drywall stud & track cold rolled machine Roll Forming Machine
Usage: In order to keep the product shape and precision, adopts
welded sheet structure, motor reducer drive, gear transmission,
roller surfaces polishing, hard plating , heat treatment and galvanize
treatment . The polished surface and the heat treatment towards
the molds also can keep the molding plate surface smooth and not
easy to be marked when it is being stamped.
Size of main part: About 5.5*1.4*1.5m (L*W*H)
Weight of main part: 4.5Tons
Main power: 5.5kw
Voltage: 380V/50HZ/3Phase
Frame type: Memorial arch frame
Frame thickness: 25mm
Drive mode: By gear
Material of rollers: GCr12MoV
Material of shafts: 45# steel with tempering
Diameter of shafts: φ40mm
Number of rollers: 11 rollers
Material: GI/PPGI
Material thickness: 0.3-0.6 mm
Forming speed: 25 meter/minute

metal steel drywall stud & track cold rolled machine

metal steel drywall stud & track cold rolled machine

metal steel drywall stud & track cold rolled machine Automatic Cutting

Feature : Ensure stability, precision and cutting speed
Function : Automatic cutting controlled by electric control system
It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products.
Material of blades: Gcr12MoV quenched
Power supply : Hydraulic power

metal steel drywall stud & track cold rolled machine

metal steel drywall stud & track cold rolled machine Hydraulic Station
It is controlled by gear wheel oil pump. After filling the hydraulic oil into the hydraulic oil tank ,the pump drive the cutter machine to begin the cutting job.
Station quantity: 2 sets
Hydraulic motor Power: 3kw
Hydraulic oil: 46# hydraulic oil
Volume: 30L
Components: The system includes a set of hydraulic tank , a set of hydraulic oil pump, two hydraulic pipes. and two sets of electromagnetism valves.

metal steel drywall stud & track cold rolled machine

metal steel drywall stud & track cold rolled machine Electric Control System
1. Adopted PLC, transducer, touch panel to ensure high speed with stability, precision and lifetime.
2. Voltage: 380V/50HZ/3Phase
3. Language: English and Chinese
4. Automatic length measurement
5. Automatic quantity measurement
6. Length Tolerance: 3m±1.5mm
7. Length inaccuracy can be amended easily.
8. Operating panel: touching screen and button together.
9. Equipped with movable switch , air break, radiator, transformer & electric leakage protector for operation convenience and safety.

metal steel drywall stud & track cold rolled machine
metal steel drywall stud & track cold rolled machine Warranty

1. One year warranty, whole life technical support.
2. Installation & adjustment : We can take a video for the customer and the customer can also come to our factory, we can train customer how to install and adjust the machine.
3. Oversea service: the buyer should charge of visa, return ticket, food and accommodation overseas and USD50/person/day salary.

metal steel drywall stud & track cold rolled machine Contact information

metal steel drywall stud & track cold rolled machinemetal steel drywall stud & track cold rolled machine


Looking for ideal Cold Rolled Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Stud & Track Cold Rolled Machine are quality guaranteed. We are China Origin Factory of Metal Steel Drywall Stud & Track Cold Rolled Machine. If you have any question, please feel free to contact us.
