Zhongtuo Roll Forming Machinery Co., ltd

10Tons pneumatic auto coil decoiler
10Tons pneumatic auto coil decoiler
10Tons pneumatic auto coil decoiler
10Tons pneumatic auto coil decoiler
10Tons pneumatic auto coil decoiler

10Tons pneumatic auto coil decoiler

Payment Type: L/C,T/T,D/P,Paypal
Incoterm: FOB,CFR,CIF
Min. Order: 1 Set/Sets
Delivery Time: 25 Days

Contact Now

Basic Info

    Model No.: ZT-008

    Safety Level: High

    Capacity: 10Tons

    Work Type: Automatic

    Press Hand: Yes Include

    Loading Hand: Yes Include

    Control System: Remote And Control Box

    Warranty: 12 Months

    Decoiler Color: As Required

    Inner Diameter: 480-550mm, Or As Required

    Product Name: Hydraulic Uncoiler

Additional Info

    Packaging: Plastic package outside the machine, make coil inside in case the roller and shaft got rusty. Steel wire fix the machine into the container, in case any damage when shaking on the sea. The machine is put near the container door, then the customer can t

    Productivity: 20m/min

    Brand: ZHOGNTUO

    Transportation: Ocean,Land,Air

    Place of Origin: CHINA

    Supply Ability: 30SETS/MONTH

    Certificate: ISO CE SGS

    HS Code: 845522


Product Description

10Tons pneumatic auto coil uncoiler

10T Hydraulic decoiler with coil car

5T auto pneumatic uncoiler

Here we zhongtuo roll forming machinery factory focus on the high quality level and middle level products. sure the products win good reputation among the customers.

with the development, more and more countries encourage the importing, and mostly import from China.

My factory can provide different design concepts to match customers' request, welcome you come to us and visit my factory.

As we provide the prodcution line for customers, here we take the auto decoiler for example.

hydraulic decoiler

The feature of the auto decoiler is that have functions compared the manual one.

Such as the press arm, loading hand and loading car.

Obviously, the loading car is the most different part beside the decoiler.

This loading car is controled by the remote. It can move forward and back up.

Especially, the height of the car can be adjusted. So that the car can put the coil on the decoiler very easily.

The max. coil weight for the car is 10 Tons.

hydraulic decoiler car

Then let's see the press arm and loading hand. Their main function is to fix the material with the coil when the decoiler stop. In case the material drop down.

Decoiler is controled by a electrical box, decoiler roll move forward and reversal is no problem.

Because of the auto move, it can save much power for the roll forming machinery.

For the speed of the decoiler also can match with the machinery.

hydraulic decoiler

hydraulic decoiler

This is the technical parameter:

Technical parameter

Coil inner diameter:460-580mm (as required)

Coil outer diameter:1500mm

Coil width:1250mm

Coil capacity:10T

Main motor power:5.5KW

Hydraulic motor power:3KW

Car motor power:0.75KW

Diameter for cylinder:150mm

Work pressure:10MPA

Machine frame material:Q235 carbon steel welded

This decoiler with the function of loading and pressing, and control by pneumatic

And the buyer should prepare for the pneumatic pump.

The machine will math one hand remote for one set.

Deociler dimension: 3.1*1.9*2.25m weight about 4T

Loading car dimension: 3*0.86*0.85-1.25m (height can be adjusted)

Loading car weight about 0.75T

For further information please feel free to let me know

zhongtuo machine

To expand our business, our government give us so much support, one of the important is the payment terms.

As most of factories and customers can make TT, sure it's very easy and convenient for people.

But there are some countries can not make the payment by TT, like Algeria, Bangladesh. They only can make LC or DP. For this kind of customer, we accept the LC and DP, especially the 100% LC.

Meanwhile, some customers have the problem for us dollars, or they can not pay a big amount one time.

For this, we can make it by OA to solve this problem. Also, OA payment terms can be a guarantee for customers. From our side, we have 100% confidence for our products and the customers.

Looking for ideal Auto Uncoil Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Hydrualic Decoiler with Car are quality guaranteed. We are China Origin Factory of 5T Decoiler. If you have any question, please feel free to contact us.
