High-Speed Metal Corner Trim Roll Forming Machine for Building Construction Customizable Profiles &

High-Speed Metal Corner Trim Roll Forming Machine for Building Construction Customizable Profiles & Sizes

This high-speed roll forming system is engineered for the continuous production of metal corner trim profiles used in building construction. Designed for efficiency and adaptability, it allows customization of profile designs and dimensions to meet diverse project requirements.
A Metal Corner Trim Roll Forming Machine is specialized industrial equipment used to fabricate protective metal edge trims for construction applications. These trims are widely employed to reinforce and protect corners in drywall, plasterboard, and other wall systems, ensuring durability and a clean finished appearance.

The machine can be tailored to produce a variety of corner trim designs with adjustments in width, thickness, and profile shape, offering flexibility for different architectural needs.

Key Specifications:

• Machine Weight: 4 tons

• Number of Roller Stations: 16–19

• Hydraulic System Power: 5.5 kW

• Production Speed: Up to 25 meters per minute

• Material Development Width: 1000–1250 mm

• Raw Material Width: 80–300 mm

• Material Thickness: 1.5–3 mm (compatible with 2.5–3.5 mm based on profile)

• Cutting System: Automatic hydraulic cut-off

• Control System: PLC-based automation

• Frame Construction: 350H/400H steel

• Spacer Treatment: Anti-rust protection

• Model No.: EN-130JK


Performance Benefits

• Delivers consistent high-quality trim profiles with precision and repeatability

• Significantly reduces labor and time compared to manual fabrication methods

• Ideal for high-volume production runs without compromising accuracy

• Enhances structural protection and aesthetic finish of building interiors and exteriors

Detailed Machine Configuration

1. Raw Material

• Types: GI (Galvanized Iron), PPGI (Pre-Painted Galvanized Iron)

• Thickness Range: 0.3–1.2 mm

• Feeding Width: As per profile drawing

2. Decoiler

• Operation: Manual

• Load Capacity: 3 tons

3. Roll Forming Assembly

• Stations: 12

• Shaft Diameter: 55 mm

• Roller Material: 45# steel with 0.05 mm chrome plating

• Frame: 16 mm welded steel plate

• Production Speed: 15–20 m/min

4. Cutting Unit

• Method: Automatic hydraulic cutting

• Blade Material: CR12 tool steel

• Control: PLC-operated

5. Power & Drive

• Main Motor: 4 kW

• Voltage: 380V/50Hz (configurable)

• Transmission: Chain drive

6. Control System

• PLC Brands: Delta (standard)

• Inverter: Delta

• Interface: Touch screen & push-button

• Languages: English/Chinese (customizable)

• Function: Adjustable target length, automatic operation

7. Hydraulic Station

• Oil Type: 46# hydraulic oil

• Oil Capacity: 3/4 of tank volume

• Pressure: 8–10 MPa

8. Additional Features

• Polished and hardened roller surfaces to minimize material marking

• User-friendly interface for easy operation and length settings

• Robust construction ensuring long-term reliability and minimal maintenance

This machine is an ideal solution for manufacturers and construction suppliers looking to produce high-quality, custom metal corner trim efficiently and reliably. Suitable for the Egyptian market and beyond.
